Specifications
WAN
- LTE-only, HSPA+, or LTE/HSPA+/EVDO
- Advanced Modem Failure Check
- Standby
LAN
- VLAN 802.1Q
- DHCP Server, Client, Relay
- DNS and DNS Proxy
- DynDNS
- UPnP
- DMZ
- Multicast/Multicast Proxy
- QoS (DSCP and Priority Queuing)
- MAC Address Filtering
MANAGEMENT
- Cradlepoint Enterprise Cloud Manager¹
- Web UI, API, CLI
- Data Usage Alerts (router and per client)
- Advanced Troubleshooting (support)
- Device Alerts
- SNMP
- SMS control
VPN AND ROUTING
- IPsec Tunnel – up to two concurrent sessions
- GRE Tunnel
- Route Filters (Access Control Lists, Prefix Filters, Route Maps, Communities for BGP)
- Routing Rules
- Policy-based Routing
- NAT-less Routing
- Virtual Server/Port Forwarding
- IPv6
- CP Secure VPN compatible*
*-Cradlepoint Secure VPN-NAT configuration only
SECURITY
- RADIUS and TACACS+ support*
- 802.1x authentication for Ethernet
- Certificate support
- ALGs
- MAC Address Filtering
- Advanced Security Mode (local user management only)
- Per-Client Web Filtering
- IP Filtering
- Content Filtering (basic)
- Website Filtering
- Zone-Based Object Firewall with host address (IP or FQDN), port, and mac address
*-Native support for authentication. Authorization and accounting support through hotspot/captive portal services.
1 – Enterprise Cloud Manager requires a subscription.
Specifications
WAN
- Integrated LTE-only, HSPA+, or LTE/HSPA+/EVDO modem
- Two 10/100 Ethernet ports (WAN or LAN)
LAN
- Two LAN 10/100 Ethernet ports (WAN or LAN)
PORTS
- Power
- Two Ethernet LAN or WAN
- Two cellular antenna connectors (SMA)
- Two WiFi connectors* (reverse SMA)
TEMPERATURE
- −20 °C to 60 °C (−4 °F to 140 °F) operating modem as WAN
- −20 °C to 50 °C (−4 °F to 122 °F) operating Ethernet as WAN
- −30 °C to 70 °C (−22 °F to 158 °F) storage
HUMIDITY (NON-CONDENSING)
- 10% to 85% operating
- 5% to 90% storage
POWER
- DC input steady state voltage range: 9 – 18VDC
- Recommended inline fuse for vehicle installations: 1.5A fast-blow
- Idle: typical=350mA@12V(4.2W)
worst case=700mA@12V(8.4W) - Tx/Rx: typical=600mA@12V(7.2W)
worst case=1200mA@12V(14.4W)
SIZE
- 3.3 in x 4.0 in x 0.9 in (85 mm x 102 mm x 22 mm)
CERTIFICATIONS
- FCC
- WiFi Alliance*
- Shock/Vibration (MIL STD 810G and SAEJ1455)
- Carrier certifications (see individual SKUs for additional certifications)
Feature Details
- WAN Security – NAT, SPI, ALG, inbound filtering of IP addresses, port blocking, service filtering (FTP, SMTP, HTTP, RPL, SNMP, DNS, ICMP, NNTP, POP3, SSH), protocol filtering, WAN ping (allow/ignore)
- Intelligent Routing – UPnP, DMZ, virtual server/port forwarding, routing rules, NAT-less routing, route management, content filtering, IP filtering, website filtering, per-client Web filtering, local DHCP server, DHCP client, DHCP relay, DNS, DNS proxy; ALGs: PPTP, SIP, TFTP, FTP, IRC; MAC address filtering, Dynamic DNS, LAN/WAN affinity, VLAN 802.1Q, multicast proxy support, IP setting overrides, IPv6 support
- Management – Enterprise Cloud Manager: cloud-enabled management and application platform (subscription-based); web-based GUI (local management), optional RADIUS or TACACS+ username/password; remote WAN web-based management w/ access control (HTTP, HTTPS); SNMP v1, v2c, & v3; CLI over SSH, SSH to serial, SSH to telnet; API; one-button firmware upgrade; modem configuration, update, and management; modem data usage w/ alerts, per-client data usage; custom AT scripting to modems
- Performance & Health Monitoring – Advanced QoS with traffic shaping, with DSCP/DiffServe QoS, Modem Health Management (MHM) improves connectivity of modem, WAN port speed control, several levels of basic and advanced logging for troubleshooting
- VPN (IPsec) – Tunnel, NAT-T, and transport modes; connect to Cradlepoint, Cisco/Linksys, CheckPoint, Watchguard, Juniper, SonicWall, Adtran and others; certificate support; Hash (MD5, SHA128, SHA256, SHA384, SHA512), Cipher (AES, 3DES, DES); support for two concurrent connections, GRE tunneling
edhill –
Nice router design. Connects without much effort other than installing a SIM card. Mine has been up for a week with no problem. Good router for the price.
John Walker –
Impressive little router. Not sure what I was expecting from a refurb product but LTE Fix seems to do a good job. I am well pleased with it. It is compact and fits in confined spaces. I use it with ATT cell phone sim card and it connected right away. My average download speed is 30mbps. It only has 2.4 N wifi but it seems to works well. I have plans to use it as a gateway modem and bridge it to my Linksys to do the routing and wifi. Be sure and buy the power adapter with the router. It is a special 4 prong pin and not one you’d have laying around.
