700-3800MHz WiFi – Cellular 7dBi Directional MIMO Antenna (± 45°) N Female Connectors

$179.35

The WiFiX ADM 1DP738X7 NF is a Wide Band (700MHz to 3800MHz) WiFi | Cellular 7dBi 2×2 MIMO Directional Antenna

    WiFiX ADM 1DP738X7 NF is a Cellular MIMO 2×2 X-Polarity 7dBi directional panel antenna with N Type Female Connectors

    NOTICE: The 1DP727X7 NF is now the 1DP738X7 NF. We have updated our 2×2 MIMO Flat Panel Directional Antenna to now support a wider frequency range from 700 Mhz to 3800 Mhz.

    The ADM 1DP738X7 NF Cellular 7dBi MIMO antenna is a wide band directional panel antenna engineered to improve signal strength and reception over a wide range of frequencies and applications.  It is ideal for rural, suburban and other locations where the mobile signal is poor or less than desirable, or where a better signal is required to take advantage of carrier aggregation.

    Its wide range design allows the antenna to be carrier neutral, covering the 700/800/850/1700/1800/1900/2100/2300/2500/2600/2700/3800 frequencies.  Its small dimensions and aesthetic appearance accommodate installations at most any location, even for high demanding applications and customers.

    This antenna is not rated for B71, though may connect. We cannot guarantee it to connect to B71.

    The antenna component and circuitry are integrated within our top quality WiFiX Medium enclosure system.  It comes with 2 x Type N Female connectors extruding through the bottom of the antenna enclosure.

    700-2700MHz WiFi 4G LTE 8dBi Directional MIMO Antenna (± 45°) N Female Connectors 4
    700-2700MHz WiFi 4G LTE 8dBi Directional MIMO Antenna (± 45°) N Female Connectors 4





    The WiFiX ADM 1DP738X7 NF is equipped with two type N female connectors:

    700-2700MHz WiFi 4G LTE 8dBi Directional MIMO Antenna (± 45°) N Female Connectors 8
    700-2700MHz WiFi 4G LTE 8dBi Directional MIMO Antenna (± 45°) N Female Connectors 8

    We recommend sealing the antenna connectors with dielectric grease and self-bonding silicon tape, when installing any outdoor antenna and cabling.

    The WiFiX ADM 1DP738X7 NF is suitable for both indoor and outdoor (IP67) installations, both wall and pole mask mounting.



    wall-mast-installations
    Wall and Mast Installations



    WiFiX systems are engineered of UV resistant ABS plastic material that is resistant to extreme weather conditions like rain, snow and humidity. They can safely operate in temperatures ranging from -40°C up to 80°C.  WiFiX designed sealing systems guarantees a waterproofed level of IP67.

    wifix-ip67
    WiFix Systems are IP67 Waterproof



    The WiSecure mounting system is engineered to couple stability and attractiveness in one product. Its design is made of a special fiberglass reinforced polyamide plastic, which is super rigid–even in extreme weather conditions.  Its innovative design and composite makeup, compared to metal brackets, offers better performance and a rust free life-time. WiSecure further enables the antenna position and aligning in two separate polarization settings.



    wisecure-mount
    LTE Fix WiSecure Antenna Mounting System
    WiSecure Antenna Mounting Detail
    WiSecure Antenna Mounting Detail



    NOTICE: This antenna listing comes with ONE WiSecure Antenna Mount included with your purchase of the antenna. You do not need to purchase a separate mounting system.



    Weight 84 oz
    Dimensions 17.25 × 11 × 4.75 in
    Antenna Type

    4G LTE Outdoor Directional

    Carrier

    AT&T, Boost Mobile (Sprint), Cricket Wireless (AT&T), FreedomPoP (Sprint), MetroPCS (T-Mobile), Mint (T-Mobile), Project Fi (Sprint, T-Mobile), Simple Mobile (T-Mobile), Sprint, T-Mobile, U.S. Cellular, Verizon, Virgin Mobile (Sprint)

    Antenna Cable Connector 1

    N Type Female Straight

    Specifications

    Carriers | Bands

    Carriers | Bands

    The ADM 1DP738X7 NF is a wide band|frequency antenna–meaning it is compatible with the vast majority of carriers.

    • LTE band – 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 23, 25, 26, 27, 28, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 48, 66,
      This antenna has been tested to pickup and use 71 very well, but it is gain is not at the rated dBi for this antenna. No guarantees can be made for your results.
    • WiMAX – 2.3 GHz, 2.5 GHz, 700 MHz
    • 3G – 2100 MHz, 850 MHz, 900 MHz
    • GSM – 1800 MHz, 1900 MHz, 850 MHz
    • RFiD – 2400 – 2483 MHz, 865 – 868 MHz, 902 – 928 MHz
    • ISM – 2400-2483 MHz, 868-870 MHz
    • WLAN – 2.4 GHz
    • Bluetooth – 2400-2483 MHz
